EN5366QI – 6A Non-Isolated PoL Module – Altera Enpirion® 5300 Series

This Altera EN5366QI non-isolated point-of-load (PoL) DC-DC converter delivers precise, efficient power regulation for space-constrained commercial applications. Engineered for reliability in demanding environments, it features integrated protections and high efficiency in a compact surface-mount package. PCX ensures genuine Altera components with fast shipping and dedicated technical support.

Key Features

• High-Efficiency Conversion: 93% peak efficiency reduces thermal stress
• Wide Input Range: 2.375V to 5.5V operation
• Adjustable Output: 0.75V to 3.3V at 6A continuous current
• Comprehensive Protections: OCP, OTP, OVP, SCP & UVLO
• Commercial Temperature Range: -40°C to +85°C
• Ultra-Compact Footprint: 12.0mm × 10.0mm × 1.9mm QFN package

Technical Specifications

• Type: Non-Isolated PoL Power Module
• Outputs: Single (1)
• Control Interface: Enable (Active High) with Remote On/Off
• Mounting: Surface Mount (SMT)
• Package: 58-PowerQFN Module
• Regulation Features: Integrated inductor, MOSFETs & controller

Typical Applications

• FPGA and processor power rails in embedded systems
• Server/network storage devices
• Industrial computing modules
• Telecommunications infrastructure
• Test & measurement equipment

About Altera (Intel® PSG)

Altera, now part of Intel’s Programmable Solutions Group, pioneered high-reliability power management ICs with their Enpirion® series. Renowned for system-level integration, Altera’s solutions minimize external components while delivering industry-leading power density and thermal performance. Their rigorous validation processes ensure compliance with commercial and industrial standards.

With decades of expertise in programmable logic and power architecture, Altera components are trusted in mission-critical applications worldwide. The Enpirion® 5300 series exemplifies their commitment to solving complex power challenges in next-generation electronics through innovative semiconductor design.

About Non-Isolated PoL DC-DC Converters

Point-of-Load converters provide localized voltage regulation directly at power-hungry components like CPUs, ASICs, and memory subsystems. Non-isolated variants offer higher efficiency and simpler designs compared to isolated modules by eliminating transformer-based voltage separation. This makes them ideal for cost-sensitive, space-constrained applications sharing a common ground plane.

Modern PoL modules like the EN5366QI integrate controllers, MOSFETs, and passive components into single packages. This “power-on-a-chip” approach simplifies PCB layout, reduces BOM costs, and accelerates time-to-market. They are fundamental in distributed power architectures for servers, networking gear, and high-performance embedded systems requiring precise voltage margining and dynamic response.

Packaging Options

Available in Tape & Reel (TR) for automated assembly or Cut Tape (CT) for prototyping needs.

Frequently Asked Questions

Q: Is this part still suitable for new designs despite being obsolete?
A: While discontinued by the manufacturer, it remains ideal for legacy system maintenance, repairs, or existing product lifecycles. PCX maintains stock for such critical needs.

Q: What documentation supports this converter?
A: Access the full EN5366QI datasheet hosted on PCXCo.com for schematics, thermal data, and layout guidelines.

Q: Can the output voltage be adjusted?
A: Yes, the output is configurable between 0.75V–3.3V via external resistors as detailed in the datasheet.

Q: Does it require external cooling?
A: The 93% efficiency minimizes heat generation. Forced airflow isn’t required below 6A in most ambient conditions, but thermal vias under the PowerQFN pad are recommended.

Q: What does “Remote On/Off” functionality provide?
A: It enables digital power sequencing via the Enable (Active High) pin, allowing system controllers to activate/deactivate the module.

Q: Are evaluation boards available for this part?
A: PCX can provide guidance on compatible Altera Enpirion® development tools – contact our technical support team for assistance.

Product images are representational; refer to datasheets for exact specifications.
