DS26C32ATN/NOPB – Quad Line Receiver for RS422/RS423 – Texas Instruments

Ensure robust data transmission in demanding environments with the DS26C32ATN/NOPB quad differential line receiver from Texas Instruments. Designed for high-noise immunity in industrial systems, this IC delivers reliable signal reception for RS422 and RS423 communication protocols. PCX provides genuine components with guaranteed quality, backed by fast shipping and dedicated technical support.

Key Features

• Interface Type: Quad Differential Line Receiver (0 Drivers / 4 Receivers)
• Protocol Support: RS422, RS423
• Voltage Supply: 4.5V to 5.5V operation
• Enhanced Signal Integrity: 60 mV receiver hysteresis
• Wide Temperature Range: -40°C to +85°C
• Package: 16-Pin PDIP (Through Hole Mount)

Technical Details

This receiver IC features four independent differential input channels optimized for balanced data transmission. The 16-DIP package (7.62mm width) ensures compatibility with legacy industrial PCBs requiring through-hole mounting. As part of Texas Instruments’ DS26C32 base product family, it provides fail-safe operation and high input impedance. Note: This part is marked obsolete by the manufacturer but remains available through PCX’s secured inventory for ongoing maintenance and repairs.

Typical Applications

• Industrial automation control systems
• Legacy data acquisition equipment
• Telecommunications infrastructure
• Motor drive interfaces
• Test and measurement instruments

About Texas Instruments

Texas Instruments (TI) is a globally recognized leader in semiconductor innovation, with decades of expertise in analog and embedded processing technologies. Their components are renowned for precision, reliability, and adherence to stringent quality standards across automotive, industrial, and communications markets.

TI’s interface product portfolio, including RS-422/RS-423 solutions like the DS26C32 series, reflects deep system-level understanding. Engineers worldwide trust TI ICs for critical applications due to consistent performance, comprehensive documentation, and long-term design support – values aligned with PCX’s commitment to supplying verified authentic parts.

About RS422/RS423 Receivers

Differential line receivers like the DS26C32ATN/NOPB are fundamental to noise-resistant data transmission over long distances. By comparing voltage differences between paired signal lines, they reject common-mode interference from motors, power surges, or EMI – a critical capability in factory floors or harsh electrical environments where single-ended interfaces fail.

These components enable reliable communication in multi-point networks and point-to-point links. RS422/RS423 standards remain vital in legacy industrial systems, medical devices, and infrastructure where upgrading entire architectures is impractical. Selecting high-quality receivers ensures signal integrity, reduces error rates, and extends equipment lifespan.

Packaging

Available in protective Tube packaging for secure handling and storage. PCX manages all logistics to prevent damage during transit.

Frequently Asked Questions

Question: Is this IC still usable despite being obsolete?
Answer: Absolutely. PCX maintains stock for repair and lifecycle extension. We verify functionality to ensure performance matches original specifications.

Question: What is the significance of 60mV hysteresis?
Answer: Hysteresis prevents output oscillation near threshold voltages by creating a “dead zone,” enhancing noise immunity in electrically noisy environments.

Question: Can this receiver handle RS485 signals?
Answer: No. While electrically similar, RS485 requires different fail-safe biasing. Use dedicated RS485 receivers for that standard.

Question: What cable lengths are supported?
Answer: Typical RS422 links achieve 1200m at 100kbps. Actual range depends on cable quality, baud rate, and noise levels – consult the datasheet for design guidance.

Question: How does PCX ensure genuine Texas Instruments parts?
Answer: We source exclusively through authorized channels and perform batch-level traceability checks, eliminating counterfeit risks.

Question: Is termination required for this receiver?
Answer: Yes. RS422 networks require a termination resistor (typically 120Ω) at the receiver end to prevent signal reflections.

Note: Product images are representational. Refer to the datasheet on PCXCo.com for exact specifications.

Secure Your Industrial Communication Solution Now!

Maintain critical systems without redesign delays. PCX has verified stock ready for immediate dispatch. Order the DS26C32ATN/NOPB today for fast delivery and reliable performance!
