CS4270-CZZ – Integrated Circuit – Cirrus Logic

IC CODEC 24BIT 105DB 24TSSOP

CS4270-CZZ – 24-Bit Stereo Audio CODEC – Cirrus Logic

Elevate your audio processing with the CS4270-CZZ stereo audio CODEC from Cirrus Logic. This high-performance integrated circuit delivers studio-grade 24-bit resolution and exceptional 105dB dynamic range for pristine sound reproduction in professional and embedded systems. While marked obsolete by the manufacturer, PCX rigorously tests remaining stock to ensure reliability for legacy designs and repairs.

Key Features

• 24-Bit Resolution for high-fidelity audio conversion
• 105dB Dynamic Range on both ADCs and DACs
• Sigma-Delta Architecture for reduced noise
• Dual ADCs/DACs enabling full stereo processing
• Flexible Power: Analog (4.75-5.25V) + Digital (3.14-5.25V)
• Surface-Mount Design: 24-TSSOP package

Technical Specifications

• Interface: Serial data interface
• Operating Temperature: -10°C to 70°C
• Package: 24-TSSOP (4.40mm Width)
• Status: Manufacturer obsolete (available while stocks last)
• Base Part: CS4270 series

Common Applications

• Professional audio mixing consoles
• Broadcast studio equipment
• High-end automotive infotainment systems
• Digital musical instruments
• Legacy industrial audio processors

About Cirrus Logic

Cirrus Logic stands at the forefront of high-precision analog and digital signal processing technology. For over three decades, they’ve pioneered audio conversion solutions trusted by industry leaders for their uncompromising quality and technical innovation. Their components consistently deliver benchmark performance in demanding audio environments.

The company’s commitment to engineering excellence is reflected in stringent manufacturing controls and extensive validation protocols. Cirrus Logic ICs undergo rigorous testing to meet exacting standards for signal integrity, power efficiency, and long-term reliability across diverse operating conditions.

About Audio CODEC ICs

Audio CODECs (Coder-Decoders) are essential for converting analog sound signals into digital data and vice versa. These integrated circuits form the core of any system requiring audio capture or playback, acting as the critical bridge between microphones/speakers and digital processors. Their quality directly impacts fidelity, noise levels, and overall user experience.

In professional audio equipment, CODEC selection determines critical parameters like dynamic range, total harmonic distortion, and sampling accuracy. Advanced features such as Cirrus Logic’s Sigma-Delta modulation enable superior noise shaping and filtering, making these ICs indispensable for applications where audio clarity is non-negotiable.

Packaging

Available in manufacturer tube packaging for secure handling and storage.

Frequently Asked Questions

Q: Is this IC suitable for new designs despite being obsolete?
A: While functional for prototyping and repairs, we recommend consulting PCX engineers for modern alternatives in production systems.

Q: Does the 105dB dynamic range apply to both recording and playback?
A: Yes, the specification applies equally to both the ADC (recording) and DAC (playback) sections.

Q: What voltage compatibility does the digital interface support?
A: The digital supply accepts 3.14V to 5.25V, offering compatibility with 3.3V and 5V logic systems.

Q: Can this CODEC process microphone signals directly?
A: It requires external amplification for microphone-level inputs but supports line-level signals.

Q: How does Sigma-Delta architecture benefit audio quality?
A: It shifts quantization noise to higher frequencies, enabling easier filtering and higher effective resolution.

Q: Are evaluation boards available for this IC?
A: Contact PCX support for legacy development tool availability.

Order Today

Secure remaining stock of this high-performance audio solution! PCX guarantees authentic Cirrus Logic components with same-day shipping and dedicated technical support. Order your CS4270-CZZ today for reliable delivery of legacy audio components!

Note: Product images are representational. Refer to datasheet for exact specifications. Datasheet available upon request via PCXCo.com support portal.
