0912283001
$2.50
CONN SIM CARD R/A SMD
ADD TO CART or call us at 800-993-9047 for immediate assistance
0912283001 – SIM Card Connector Right Angle SMD – Molex
The Molex 0912283001 is a right-angle surface-mount SIM card connector engineered for reliable subscriber identity module interfacing in space-constrained electronics. Featuring an integrated ejector mechanism and gold-plated contacts, this solution ensures durable, high-integrity connections for mission-critical communication devices. PCX supplies this connector with guaranteed quality and rapid shipping.
Key Features
Card Type: Standard SIM Card
Mounting: Surface Mount (SMD), Right Angle
Positions: 8 (6 + 2 configuration)
Contact Finish: Gold (0.10µm thickness)
Ejector Side: Left-hand operation
Insertion/Removal: Push In/Push Out mechanism
Height Above Board: 3.00mm (0.118″)
Technical Details
Part of Molex’s 91228 series, this SIM connector integrates both connector and ejector in a single unit. Its surface-mount design with board guides ensures precise PCB alignment during automated assembly. The right-angle orientation optimizes PCB space utilization while the gold-plated contacts deliver low resistance and oxidation resistance. Operational features include a built-in switch for card detection and standard-top mounting.
Typical Applications
Mobile phones and smartphones
IoT devices and M2M communication modules
Portable medical monitoring equipment
GPS trackers and navigation systems
Additional Information
| Category | Connectors, InterconnectsMemory ConnectorsPC Card Sockets |
|---|---|
| Brand | Molex |
| Manufacturer | Molex |
| Series | 91228 |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Card Type | SIM Card |
| Number of Positions | 8 (6 + 2) |
| Connector Type | Connector and Ejector |
| Insertion, Removal Method | Push In, Push Out |
| Ejector Side | Left |
| Mounting Type | Surface Mount, Right Angle |
| Features | Board Guide, Switch |
| Height Above Board | 0.118" (3.00mm) |
| Mounting Feature | Normal, Standard – Top |
| Contact Finish | Gold |
| Contact Finish Thickness | 3.94µin (0.10µm) |
| Base Product Number | 091228 |
| Full Description | 0912283001 |
