XL74LS10 – Logic Gate (Triple 3-Input NAND) – Xinluda

The Xinluda XL74LS10 is a triple 3-input positive-NAND gate in a surface-mount SOP-14 package, built on the low-power Schottky (74LS) TTL logic family. Available for RFQ through Pacific Component Xchange.

The XL74LS10 from Xinluda is a triple 3-input positive-NAND gate integrated circuit belonging to the popular 74LS low-power Schottky TTL logic family. It packs three independent 3-input NAND gates into a single surface-mount SOP-14 package, making it a versatile building block for combinational logic, signal gating, and glue-logic designs. The “XL” prefix denotes the SOP (surface-mount) variant; the functionally identical DIP-14 through-hole version is offered as the XD74LS10.

As a member of the long-established 7400 logic series, the XL74LS10 offers pin-compatible, drop-in replacement behavior with other vendors’ 74LS10 devices, while delivering the low power consumption and improved speed characteristic of the low-power Schottky process. It is intended for standard 5 V TTL systems and the commercial 0 C to +70 C temperature range.

Key Features

• Function: Triple 3-input positive-NAND gates (three independent gates per package)
• Logic family: 74LS low-power Schottky TTL
• Recommended supply voltage (Vcc): 4.75 V to 5.25 V (nominal 5 V)
• Operating free-air temperature range: 0 C to +70 C (commercial)
• High-level input voltage (VIH): 2 V min
• Low-level input voltage (VIL): 0.8 V max
• Totem-pole (active push-pull) outputs
• Package: SOP-14 surface-mount
• Pin-compatible drop-in for industry-standard 74LS10 devices

Applications

• Combinational and glue logic in 5 V TTL systems
• Signal gating, enabling, and decoding
• Industrial control and instrumentation boards
• Legacy equipment repair and board-level maintenance
• Consumer and white-goods electronics
• Education and prototyping

Why Source XL74LS10 from Pacific Component Xchange

The XL74LS10 is a low-cost commodity logic IC that frequently carries little to no authorized-distributor stock outside of a single regional source, making it a hard-to-find part when a build calls for matched lots or large volumes. Pacific Component Xchange specializes in locating hard-to-find, allocated, and end-of-life components like this one. Request a quote and our sourcing team will track down verified inventory to match your quantity and schedule.

We back every order with rigorous authenticity and counterfeit-avoidance screening, full traceability where available, and worldwide shipping to your dock. Whether you need a handful of units for a repair or a production-volume lot of the XL74LS10, submit an RFQ and let Pacific Component Xchange handle the hunt.
