What is the Xinluda XL232Z?

The XL232Z is a +5V-powered RS-232 transceiver from Xinluda with two drivers and two receivers. It uses an integrated dual charge pump and four external 1 uF capacitors to generate RS-232 line voltages from a single +5V supply, supporting data rates up to 120 kbps.

Is the XL232Z a drop-in replacement for the MAX232?

Yes. The XL232Z is pin-compatible with the industry-standard MAX232 family (including MAX232C, MAX232D and ST232 variants) and can serve as a second-source or drop-in replacement in existing SOP-16 RS-232 interface designs.

What package does the XL232Z come in?

The XL232Z is supplied in a 16-pin SOP-16 surface-mount package. The 'Z' suffix in the part number designates the SOP-16 package option in Xinluda's RS-232 family, distinguishing it from the DIP-16 (XD232) and SOP-16K (XL232K) variants.

What external components does the XL232Z require?

The XL232Z requires four external 1 uF capacitors for the charge-pump and reservoir circuitry, plus the +5V supply and ground. No external positive or negative supplies are needed because the charge pump generates the RS-232 line voltages internally.

What is the operating temperature range of the XL232Z?

The XL232Z operates over an industrial temperature range of -40 C to +85 C, making it suitable for industrial and embedded serial communication applications.

Is the XL232Z hard to find, and can Pacific Component Xchange source it?

The XL232Z is a niche Xinluda part with limited authorized-distributor availability. Pacific Component Xchange specializes in sourcing hard-to-find interface and power-management ICs. Submit an RFQ and our team will respond with availability, lead time and pricing for your quantity.

XL232Z – RS-232 Transceiver – Xinluda

The XL232Z by Xinluda is a +5V-powered, 2-driver/2-receiver RS-232 transceiver in a SOP-16 package, operating at up to 120 kbps with an integrated dual charge pump. It is a pin-compatible drop-in replacement for the industry-standard MAX232.

Brand:Xinluda

SKU: XL232Z Categories: Electronic Parts, RFQ

Please contact us or add to quote for current pricing and availability.

The XL232Z from Xinluda is a +5V-powered, multichannel RS-232 line driver/receiver designed for the EIA/TIA-232E and V.28/V.24 serial communication interfaces. Integrating two drivers, two receivers, and a dual charge-pump voltage converter, the XL232Z generates the required RS-232 line voltages from a single +5V supply using just four external 1 uF capacitors. It is a pin-compatible, drop-in alternative to the industry-standard MAX232, making it a popular second-source option for legacy and cost-sensitive serial-interface designs.

Key Features

+5V single-supply operation with integrated dual charge pump
2 drivers / 2 receivers (dual RS-232 transceiver)
Data signaling rate up to 120 kbps
Requires four external 1 uF charge-pump/reservoir capacitors
Driver output slew rate limited to less than 30 V/us (typically 24 V/us unloaded)
Receiver input hysteresis typically 0.5 V (0.2 V minimum guaranteed)
Receiver propagation delay typically 600 ns
Meets EIA/TIA-232E and V.28/V.24 interface requirements
SOP-16 package
Operating temperature range: -40 C to +85 C
Pin-compatible replacement for the MAX232 family (including MAX232C / MAX232D / ST232)

Applications

UART-to-RS-232 serial port interfaces
Industrial and factory automation equipment
Point-of-sale (POS) terminals and metering
Embedded systems, microcontroller serial links and modems
Battery-powered and portable serial communication devices
Legacy equipment maintenance and MAX232 second-sourcing

Why Source XL232Z from Pacific Component Xchange

The XL232Z is a niche, hard-to-find component with little to no authorized-distributor stock in North America. Pacific Component Xchange specializes in sourcing scarce and obsolete interface and power-management ICs like the Xinluda XL232Z. As an independent distributor, we help engineers and procurement teams locate hard-to-find and end-of-life parts, verify authenticity, and ship globally. Submit a Request for Quote (RFQ) for the XL232Z and our sourcing team will respond with current availability, lead time, and pricing for your required quantity.

Request a quote today to secure XL232Z inventory and avoid costly redesigns or production delays.

Additional Information

Manufacturer	Xinluda
Component Type	RS-232 Transceiver (Line Driver/Receiver)
Channels	2 Drivers / 2 Receivers
Supply Voltage	+5 V (single supply)
Data Rate	Up to 120 kbps
External Capacitors	4 x 1 uF
Charge Pump	Integrated dual charge pump
Standards	EIA/TIA-232E, V.28/V.24
Operating Temperature	-40 C to +85 C
Compatibility	Pin-compatible with MAX232 / ST232
Package	SOP-16
Part Status	Active
Availability	Available
