XD74LS181 – 4-Bit Arithmetic Logic Unit (ALU) / Function Generator – Xinluda

The Xinluda XD74LS181 is a 4-bit Arithmetic Logic Unit (ALU) and function generator in a DIP-24 package, performing 16 logic and 16 arithmetic operations on two 4-bit words with full look-ahead carry. Available for RFQ at Pacific Component Xchange.

The XD74LS181 from Xinluda is a 4-bit Arithmetic Logic Unit (ALU) and function generator, a Low-Power Schottky (74LS) TTL implementation of the classic 74181 architecture. It performs a comprehensive set of arithmetic and logic operations on two 4-bit operands, selected by four function-select lines, making it a foundational building block for processors, controllers, and digital computation circuits. The device supports full internal look-ahead carry generation for high-speed operation on longer words when multiple units are cascaded.

Key Features

• 4-bit Arithmetic Logic Unit (ALU) and function generator
• Performs 16 logic operations on two variables (including AND, NAND, OR, NOR, XOR, XNOR)
• Performs 16 arithmetic operations (including add, subtract, compare, and shift/double)
• Four function-select lines (S0, S1, S2, S3) plus mode control
• Full internal look-ahead carry for high-speed operation on long words (cascadable)
• Low-Power Schottky (74LS) TTL technology
• Operating supply voltage range: 4.75 V to 5.25 V (5 V nominal)
• DIP-24 through-hole package
• RoHS compliant

Applications

• CPU and ALU sections of discrete-logic processors and microcoded designs
• Educational and hobbyist TTL computer builds
• Legacy industrial and instrumentation control boards
• Digital arithmetic and comparison circuits
• Repair and maintenance of vintage / legacy equipment
• FPGA-to-discrete-logic prototyping reference designs
