XD14514 – CMOS 4-Bit Latch / 4-to-16 Line Decoder – Xinluda

About this part

The XD14514 from Xinluda is a CMOS 4-bit latch / 4-to-16 line decoder belonging to the industry-standard 4514 logic family. The device combines a 4-bit strobed input latch with a 4-to-16 line decoder, presenting a logic “1” on one of sixteen mutually exclusive outputs selected by the 4-bit binary address. An Inhibit input forces all outputs low, and a Strobe / Latch Enable input freezes the stored address so the active output is held independent of subsequent input changes. The XD14514 is a pin- and function-compatible equivalent of the classic CD4514 / MC14514 type devices.

Key Features

• CMOS 4-bit latch combined with a 4-to-16 line decoder
• 16 mutually exclusive, fully decoded outputs (active-high)
• Wide supply voltage range: 3.0 V to 15 V
• Strobe / Latch Enable input for holding the decoded address
• Inhibit input to disable (blank) all outputs
• High noise immunity and low quiescent power, typical of 4000-series CMOS
• DIP-24 through-hole package

Applications

• Address and bank decoding in microprocessor and memory systems
• Keyboard, keypad and switch scanning / encoding
• Demultiplexing of data to one of sixteen lines
• Lamp, LED and indicator drivers (one-of-sixteen selection)
• Industrial control and instrumentation logic

Why Source XD14514 from Pacific Component Xchange
