K4B4G1646E-BYMA – DDR3L SDRAM – Samsung

Samsung K4B4G1646E-BYMA is a 4Gb DDR3L SDRAM (E-die) organized as 256M x 16 in a 96-ball FBGA package, rated for DDR3L-1866 operation at 1.35V. This part has been discontinued by Samsung and is available for RFQ from Pacific Component Xchange.

The Samsung K4B4G1646E-BYMA is a 4 Gigabit DDR3L (low-voltage DDR3) SDRAM from Samsung’s E-die family. It is organized as 256M x 16 (32M x 16 I/Os x 8 banks) and packaged in a 96-ball FBGA, making it well suited for x16 memory subsystems in embedded, networking, and industrial designs. The device supports a maximum data rate of 1866 Mbps/pin (DDR3L-1866) at a 933 MHz clock and operates from a 1.35V (1.28V to 1.45V) supply for reduced power consumption versus standard DDR3.

Key Features

• Density: 4 Gigabit (4Gb)
• Organization: 256M x 16 (32M x 16 I/Os x 8 internal banks)
• Memory type: DDR3L SDRAM, Samsung E-die
• Data rate: up to 1866 Mbps/pin (DDR3L-1866), 933 MHz clock
• Speed grade: BY suffix (DDR3L-1866, 13-13-13 CL-tRCD-tRP)
• Supply voltage: 1.35V (1.28V to 1.45V), VDD = VDDQ
• Package: 96-ball FBGA (7.5 x 13.3 mm)
• 8 internal banks for concurrent operation
• DDR3 feature set: posted CAS, programmable CWL, on-die termination (ODT), ZQ calibration, asynchronous RESET, auto precharge

Applications

• Embedded and industrial computing systems
• Networking and telecom line cards / routers
• Set-top boxes, digital displays and signage
• Single-board computers and SOM/COM modules
• Legacy and long-lifecycle DDR3L memory designs

Why Source K4B4G1646E-BYMA from Pacific Component Xchange

The K4B4G1646E-BYMA is a specialized x16 DDR3L memory device that has been discontinued by Samsung and is increasingly difficult to obtain through authorized distribution as DDR3-generation parts reach end of life. Pacific Component Xchange is an independent distributor focused on hard-to-find and obsolete memory, helping engineers and procurement teams keep mature and long-lifecycle designs in production.

We support rigorous authenticity and incoming-inspection processes to guard against counterfeit components, and we ship worldwide to meet tight build schedules. Pricing for this part is provided by quote. Request an RFQ today and our team will respond quickly with availability, lead time, and pricing for your required quantity.
