Pacific Component Xchange, Inc only works with top quality products and trusted partners. One of these trusted partners is Amphenol RF Products.
Amphenol RF is the world’s largest manufacturer of coaxial connectors for use in radio frequency, microwave, and data transmission system applications. Headquartered in Danbury, Connecticut, USA, Amphenol RF has global sales, marketing and manufacturing locations in North America, Asia and Europe.
Amphenol RF utilizes the most advanced manufacturing technology in the industry, along with Statistical Process Control to produce coaxial connectors and cable assemblies in high volume with superior quality. The result is the largest portfolio of Radio Frequency interconnect products which meet the most exacting RF and data systems requirements, either military or commercial.
PCX x Amphenol RF
Coming together to provide the best quality products while having fast lead times and top cost efficiency.
HD-BNC Straight Crimp Jack for RG-316
Part # 034-5019
A RF Connector that’s an HD-BNC Straight Crimp Jack for RG-316 with a Bulkhead and 50 Ohm.
Key Features:
- Body Finish – Nickel
- Body Material – Brass
- Contact Finish – Gold
- Contact Material – Beryllium Copper
- Contact termination Style – Solder
- Insulator Material – PTFE
- Cable Group – B
- Coupling Mechanism – Bayonet
- Polarity – Standard
- Min. Temp. (Celcius) – -65
- Max. Temp. (Celcius) – 165
- Mating Cycles – 500
- Weight (Grams) – 3.65
MMCX Straight Crimp Plug for RG-316
Part # 908-NM41300
A RF Connector with a MMCX Straight Crimp Plug for RG-316 that’s Non-Magnetic and 50 Ohm.
Key Features:
- Body Finish – White Bronze
- Body Material – Brass
- Contact Finish – Gold
- Contact Material – Beryllium Copper
- Contact Termination Style – Solder
- Insulator Material – PTFE
- Cable Group – B
- Coupling Mechanism – Push-on
- Non-Magnetic – Yes
- Polarity – Standard
- Min. Temp. (Celcius) – -65
- Max. Temp. (Celcius) – 165
- Mating Cycles – 500
SMP Straight PCB Jack
Part # SMP-MSLD-PCT16T
A RF Connector with a SMP Straight PCB Jack, Male Contact Pin, Through Hole, Limited Detent, Tape & Reel, and 50 Ohm.
Key Features:
- Body Finish – Gold
- Body Material – Brass
- Contact Finish – Gold
- Contact Material – Brass
- Contact Termination Style – Solder
- Insulator Material – PEEK
- Coupling Mechanism – Push-on
- Detent Type – Limited Detent
- Min. Temp. (Celsius) – Standard
- Max. Temp. (Celsius) – 165
- Mating Cycles – 500
- Weight (Grams) – 0.5
Quality is the focal point of Pacific Component Xchange, Inc. From our many certifications to our industry famous 67 step Star Quality Program, we deliver the right product at the right time. At PCX, we continuously improve our processes in order to meet and exceed our customers’ expectations. All employees understand what our customers expect and they provide our customers with the best service.
All PCX processes are continuously re-evaluated and upgraded to reflect changing customer expectations, ensuring only the highest quality of products and services are delivered to them.
